This sliting machine is our latest product,Which is based on years of production and development of similar products. Suitable for processing variety of single and double layer cash paper, fax paper, etc. Simple operation, high degree of automation, superior performance, Accurate slitting,fast speed, and smooth end face.

There are two models for customer’s selection: single shaft and double shafts. In order to reduce labor intensity and improve working efficiency, The single model adopt with the electric automatic paper feeder, but the function for the double model need to choice the paper hanger.

Slitter is equipped with the latest automatic control system, One button control in the whole process. Adopted transducerad just the working speed, PLC control system, touch screen, automatic tension conteoller, automatic mark devices. Simple operation, quick adjustment. This press is made of high-quality materials, parts, with advanced technology, and selected import bearings, ensure the durable!

Technical parameters:

Max. Paper Width：650mm/900mm

Max. Unwind Diameter：φ1200mm

Unwind Core Diameter：φ76 mm

Slitting Speed ：Max150m/min(frequency control of motor speed)

Rewind Diameter：

254 mm  (below circular knife is 97mm)

180 mm  (below circular knife is 70mm)

Main Motor：2.2KW

 Power: 220V50HZ/3PH380V50HZ

 Air Source: 0.8Mpa Dry and clean compressed air 0.8Mpa
